MC 25 (TH) – Wagon Drill
Model # | MC 25 (TH) | |
Version | Top Hammer | |
Pneumatic Drifter | MC 120F | BBC 120F | |
Drilling Depth | 20 - 40 mm | 66 - 131 ft |
Hole Diameter | 45 - 75 mm | 1.8 - 3" |
Drill Steel | R32, R38, T38 | |
Drill Steel Length | 1.20m, 2.50m, 3m | |
Air Consumption | 400 cfm at 7 bar | |
Feed Type | Chain Drive | |
Feed Beam Length | 5430 mm (5.4 mtr), 4425 mm (4.4 mtr), 2825 mm (2.8 mtr) | |
Travel Length | 3940 mm (3.9 mtr), 2200 mm (2.2 mtr), 1500 mm (1.5 mtr) | |
Feed Force | 8 kN | 1.8 lb |
Boom Type | Single section hand operated Hydraulic cylinder | |
