MC 50 – Rock Drill Lubricator
Model # | MC 50 Litre | |
Oil Volume | 0.71 litre | 0.19 gallon |
Length | 200 mm | 8 " |
Diameter | 115 mm | 4 ½ " |
Weight Empty | 3.5 kg | 8 lb |
Weight Full | 5.5 kg | 12 lb |
Pressure Rated (Operating Max) | 17 bar | 250 psi |
Safety Fill Cap Diameter | 48 mm | 1 ⅞" |
Pressure Tested to Destruction* | 83 bar | 1200 psi |
Pipe Thread Size at Intake or Outlet | 32 mm | 1 ¼" |
Bushing Sizes Available | 32,25 mm or 19 mm | 1 ¼ - 1 " or ¾” |
