Simba Junior Standard
Model # | (Standard) Simba Junior | |
Weight | 850 kg | 1874 lb |
Pneumatic drifter | MC 120F | |
Hole diameter | 34 – 64 mm | 1.3 – 2.5″ |
Drill rod size | R32, R38, T38 | |
w | 1.20 metres | 4 ft |
w | 25 mtr. max. | 82 ft |
Air consumption | 400 cfm | 189 l/s |
Drilling rate | 1 meter in 4 minutes | |
Feed beam | Screw feed type (BMS 46) | |
w | Pneumatic Type (BSP 10) | |
Ring size | 1500 mm | 59" |
w | 1780 x 1550 x 2600 mm | 70″ X 61″ X 102″ |
Column bar height | Closed – 2200 mm, Open – 3700 mm | Closed – 87″, Open – 146″ |
